Kyaw Stainless, a well-known manufacturer and supplier in Naypyidaw, Myanmar, has been manufacturing high-quality AWS Class ER385 MIG and TIG Filler Welding Wires and Rods intended for welding super austenitic stainless steels. They offer superior corrosion resistance in aggressive chemical and acid media, such as seawater and chloride media. Kyaw Stainless provides accurate composition, smooth feeding, and consistent weld integrity. ER385 is the best product to use where maximum corrosion resistance is required, for example, chemical processing, desalination, and marine uses. The excellent weldability and strength of the product make it the best solution for critical stainless steel fabrications.
ER385 filler wires consist of chromium (19–21%), nickel (24–26%), molybdenum (4–5%), and minimal carbon (<0.03%) with equally adjusted levels of manganese and silicon. The weld metal contains tensile strength of about 600 MPa, yield strength of 400 MPa, and elongation of about 35%. The composition provides superior resistance to pitting, crevice, and stress corrosion cracking in chloride-bearing environments. ER385 has superior mechanical stability and toughness even after prolonged exposure to high temperature and corrosive media and is therefore ideal for severe industrial conditions.
| Classification | AWS A5.9, ER385 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Current | MIG-DCEP / TIG-DCEN |
| Diameters | .023”, .030”, .035”, .045”, 1/16”, 3/32”, 1/8” |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ER385 MIG & TIG Filler Metal Application & uses |
|
C | Mn | Si | Cr | Ni | Mo | S | P | Cu | |
Standard | ≤0.025 | 1.00-2.50 | ≤0.50 | 19.5-21.5 | 24.0-26.0 | 4.20-5.20 | ≤0.030 | ≤0.020 | 1.20-2.00 |
Test | 0.013 | 1.93 | 0.21 | 20.5 | 25.10 | 4.67 | 0.003 | 0.012 | 1.69 |
| Tensile Strength (psi) | 86,000 psi (593 MPa) |
|---|---|
| Yield Strength (psi) | 57,000 psi (393 MPa) |
| Elongation (%) | 42% |
Contact us to get a quick quote for your requirement.
Available in sizes from 0.8mm to 1.6mm, offers excellent corrosion resistance for welding high-alloy stainless steels. Ideal for critical industrial applications.
Ranging from 1.0mm to 3.2mm, provides superior corrosion resistance. Perfect for precision welding of high-alloy stainless steels in demanding environments.
Available in sizes from 1.0mm to 3.2mm, ensures excellent corrosion resistance. Suitable for welding high-alloy stainless steels in various industrial applications.
AWS Class ER385 MIG and TIG filler welding rod and wire find extensive application in chemical processing, marine, food processing, and pharmaceutical industries where excellent corrosion resistance is needed. They are used for welding stainless steel parts that are subjected to severe acidic and chloride-containing environments, including heat exchangers, piping systems, and storage tanks. They are also best suited for repairing or making medical equipment and high-strength industrial equipment. Their superior weldability and pitting and crevice corrosion resistance make them a must for precision welding applications.
AWS ER385 Class MIG and TIG filler wires and rods are employed for welding stainless steels like alloy 904L and other similar super austenitic grades. Typical applications include chemical processing facilities, offshore platforms, and seawater equipment where high corrosion resistance is needed. These fillers meet the requirements in acidic and chloride environments, including heat exchangers, tanks, and piping systems. ER385 provides a consistent arc, smooth bead finish, and cracking resistance and is perfect for fabrication and maintenance welding in severe corrosive conditions.
